Cannondale Scalpel HT Carbon 3

Details

• Platform

  Scalpel HT
• Model Name

  Scalpel HT Carbon 3
• Model Code

  C25035U

Frameset

• Frame

  Scalpel HT Carbon, Proportional Response Design, PF30-83, tapered head tube, 55mm chainline, Speed Release 12mm thru axle w/UDH hanger
• Fork

  RockShox Recon Silver RL, 110mm, DebonAir, 15x110mm thru-axle, tapered steerer, 44mm offset, remote lockout
• Headset

  Integrated Sealed Bearing, Tapered

Drivetrain

• Rear Derailleur

  Shimano Deore M6100 SGS
• Shifters

  Shimano Deore M6100, 12-speed
• Chain

  Shimano Deore M6100, 12-Speed
• Crank

  Shimano MT512, 55mm chainline, 32T
• Rear Cogs

  Shimano Deore M6100, 10-51, 12-speed
• Bottom Bracket

  PF30 83A to 24mm thread together BB

Brakes

• Brakes

  Shimano MT400 4-piston hydraulic disc, 180/160mm RT54 rotors
• Brake Levers

  Shimano MT400 hydraulic disc

Wheels

• Rims

  WTB ST i25 TCS, 32h, tubeless ready
• Spokes

  Stainless Steel, 14g
• Tire Size

  2.4
• Wheel Size

  29
• Hubs

  (F) Shimano TC500, 15x110mm / (R) Shimano TC500, 12x148mm, MicroSpline, centerlock
• Tires

  (F) Maxxis Rekon Race WT, 29x2.4", EXO Protection, tubeless ready / (R) Maxxis Aspen WT, 29x2.4", EXO Protection, tubeless ready
• Front Tire

  Maxxis Rekon Race WT, 29x2.4", EXO Protection, tubeless ready
• Rear Tire

  Maxxis Aspen WT, 29x2.4", EXO Protection, tubeless ready

Components

• Handlebar

  Cannondale 2 Flat, butted 2014 Alloy, 31.8mm, 3° rise, 8° sweep, 760mm
• Stem

  Cannondale C2, 6061 Alloy, 31.8, 7°
• Grips

  SRAM Silicone
• Saddle

  Cannondale Scoop Shallow Elite, cro-mo rails
• Seatpost

  RaceFace Ride, 27.2, 400mm
