Cannondale Moterra SL 1

Details

• Platform

  Moterra SL
• Model Name

  Moterra SL 1
• Model Code

  C65195U

Frameset

• Frame

  Moterra SL Carbon, 150mm travel, Proportional Response Tuned Suspension, FlexPivot Chainstay, direct mount internal battery, engineered plastic skid plate, 55mm chainline, internal cable routing, 29” FlipChip, 148x12mm Maxle thru-axle, UDH hanger, 200mm native post mount brake, angle adjust headset
• Fork

  Fox Float Factory 36, 160mm travel, Grip X2 Damper, Kashima coating, 15x110mm Kabolt thru-axle, tapered steerer, 44mm offset
• Headset

  Acros Adjustable Angle (1.2°)
• Rear Shock

  Fox Float X Factory, 2 pos adj, EVOL LV, 210x55mm

E-System

• Drive Unit

  Shimano EP801, 85Nm, Custom Tuned, Eco, Trail 1, Trail 2, Boost Modes
• Battery

  Custom 601Wh battery
• Charger

  Custom 4A
• Display

  Shimano SC-EM800 Cycle Computer, Bluetooth LE Compatible

Drivetrain

• Rear Derailleur

  SRAM XO Eagle AXS, T-Type
• Shifters

  SRAM AXS POD Controller
• Chain

  SRAM XO Eagle, T-Type, 12-speed
• Crank

  e*thirteen e*spec Race Carbon, 160mm (S/M), 165mm (L/XL), 34T
• Rear Cogs

  SRAM XO Eagle, 10-52, T-Type, 12-speed

Brakes

• Brakes

  Magura MT7 4-piston hydraulic disc, 203/203mm Storm HC 6-bolt rotors
• Brake Levers

  Magura MT7 HCW hydraulic disc

Wheels

• Rims

  DT Swiss XM 1700 Spline, 30mm inner width, TC tubeless ready
• Spokes

  DT Swiss Competition, straight-pull
• Tire Size

  2.5
• Wheel Size

  297
• Hubs

  (F) DT Swiss 350, 15x110mm / (R) DT Swiss 350 Ratchet System 36 SL, 12x148mm
• Tires

  (F) Maxxis DHF, 29x2.5", 3C, EXO+, tubeless ready / (R) Maxxis Dissector, 27.5x2.4", 3C, EXO+, tubeless ready

Components

• Handlebar

  HollowGram SAVE riser bar, Carbon, 35mm clamp, 30mm rise, 8° sweep, 5° rise, 780mm
• Stem

  Cannondale 1, 7075 Alloy, 1-1/8", 35mm, 0°
• Grips

  Cannondale TaperRidge
• Saddle

  Fizik Terra Aidon X3, Mobius Kium alloy rail
• Seatpost

  OneUp V3, internal routing, 31.6, 180mm (S), 210mm (M/L), 240mm (XL)

Extra

• Extra 1

  Tubeless valves, SRAM AXS charger
