Cannondale Jekyll 2

Details

• Platform

  Jekyll
• Model Name

  Jekyll 2
• Model Code

  C21202U

Frameset

• Frame

  165mm travel, Carbon, Proportional Response Tuned, Guidler idler pulley/chainguide, BSA 73, ISCG05, tapered head tube, Ai Offset
• Fork

  RockShox Zeb Select, 170mm, 15x110mm thru-axle, tapered steerer, 44mm offset
• Headset

  Integrated Sealed Bearing, Tapered
• Rear Shock

  Fox Float X Performance Series, EVOL Air, piggyback reservoir, 2 position firm mode, rebound adjust, 205x65 Metric Trunnion

Drivetrain

• Rear Derailleur

  Shimano Deore M6100
• Shifters

  Shimano Deore M6100, 12-speed
• Chain

  Shimano Deore 6100, 12-speed
• Crank

  Shimano Deore 6120, 30T, 55mm CL
• Rear Cogs

  Shimano Deore M6100, 10-51, 12-speed
• Bottom Bracket

  Shimano Deore BSA 73

Brakes

• Brakes

  Shimano M6120 hydraulic disc, 203/203mm RT64 rotors
• Brake Levers

  Shimano M6120 hydraulic disc

Wheels

• Rims

  WTB STX i30 TCS, 32h, tubeless ready
• Spokes

  Stainless steel, 14g
• Tire Size

  2.5
• Wheel Size

  29
• Hubs

  (F) Shimano MT400, 15x110mm thru-axle / (R) Shimano MT410, 12x148mm thru-axle
• Tires

  (F) Maxxis Assegai, 29x2.5", Dual compound, EXO+ puncture protection, tubeless ready, (R) Maxxis Minion DHR II, 29x2.4", EXO+, tubeless ready
• Front Tire

  Maxxis Assegai, 29x2.5", Dual compound, EXO+ puncture protection, tubeless ready
• Rear Tire

  Maxxis Minion DHR II, 29x2.4", EXO+, tubeless ready

Components

• Handlebar

  Cannondale 3 Riser, 6061 Alloy, 30mm rise, 8° sweep, 6° rise, 780mm
• Stem

  Cannondale 3, 6061 Alloy, 31.8, 0°
• Grips

  Cannondale TrailShroom
• Saddle

  Cannondale Stage 3
• Seatpost

  TranzX dropper, internal routing, 31.6, 130mm (S), 150mm (M-XL)

Extra

• Extra 1

  Jekyll Custom Fender
